Barcode Scanner HONEYWELL HF680 - A0161219

Brand : HONEYWELL

Model : HF680 (2D)

Support Barcode Type : 1D, 2D

Interface : USB / RS-232

Light Source : Illuminance : 0-100,000 Lux

Sensor Resolution : 1280 x 800 pixel

Scan Rate : Up to 2.5 m/s for 13 mil UPC at optimal focus

Scan Angle : Pitch, Skew : +/-60°, +/-70°

Field of View : Horizontal : 47°

Vertical : 30°

Depth of Field : 5.0 mil Code 39 0 mm - 100 mm

6.7 mil PDF 0 mm - 110 mm

10 mil DM 0 mm - 90 mm

13 mil UPC-A 0 mm - 210 mm

20 mil Code 39 0 mm - 300 mm

20 mil QR 0 mm - 210 mm

* Minimum Resolution: 1D: 3 mil; 2D: 6.7 mil

* Performance may be impacted by barcode quality and environmental conditions.

PCS : 20% minimum reflectance difference

Support Symbol : Reads standard 1D, PDF, 2D Symbologies

* Decode capabilities dependent on kit configuration.

Trigger Mode : N/A

Sensor : N/A

Power Supply : Input voltage : 5 VDC ±0.5V

Working : 2.0 W (400 mA @ 5V)

Standby : 0.85 W (170 mA @ 5V)

Enviroment : Operating temperature : -10°C to 40°C (14&...
